■LAN-CO 701EPI
LINE Interface
- Connector RJ45 x 1
- Compliance IEEE 802.3/802.3u
- PoE Passive PoE PSE
LAN Interface
- Connector RJ45 x 1
- Compliance IEEE 802.3/802.3u
- PoE
Power Input 2-pin Terminal Block 55-57 VDC
System Power Consumption <3 watt
Physical Dimensions (W x H x D): 47 x 26.5 x 94 mm, Metal Enclosure
Environment
Operating Temperature: -40°C~75°C,Humidity: 0%~95%RH (non-condensing)
Regulatory Compliances
CE, FCC Part 15, EN62368, EN61000-4-5, EN50121-4 Compliant
weight 0.23 kg
■LAN-CPE 101EPI
LINE Interface
- Connector
RJ45 x 1
- Compliance
IEEE 802.3/802.3u
- PoE
Passive PoE PD
LAN Interface
- Connector
RJ45 x 1
- Compliance
IEEE 802.3/802.3u/802.3at/802.3af
PoE
PSE
Power Input
Powered by LINE interface
System Power Consumption <3 watt
Physical
Dimensions (W x H x D): 47 x 26.5 x 94 mm, Metal Enclosure
Environment
Operating Temperature: -40°C~75°C,Humidity: 0%~95%RH (non-condensing)
Regulatory Compliances
CE, FCC Part 15, EN62368, EN61000-4-5, EN50121-4 Compliant
weight
0.23 kg
本型錄內容若有變更，恕不另行通知
